Capillary | Heparin | Length | Outerø | Packaging pcs. |
~90 μl | ~50 I.U. | ~80 mm | ~1,75 mm | 10 x 100 |
~100 μl | ~50 I.U. | ~90 mm | ~1,75 mm | 10 x 100 |
~110 μl | ~50 I.U. | ~100 mm | ~1,75 mm | 10 x 100 |
~130 μl | ~50 I.U. | ~120 mm | ~1,75 mm | 10 x 100 |
~165 μl | ~50 I.U. | ~150 mm | ~1,75 mm | 4 x 250 |
~200 μl | ~50 I.U. | ~180 mm | ~1,75 mm | 4 x 250 |
~140 μl | ~50 I.U. | ~90 mm | ~2,35 mm | 10 x 100 |
~155 μl | ~50 I.U. | ~100 mm | ~2,35 mm | 10 x 100 |
~185 μl | ~50 I.U. | ~120 mm | ~2,35 mm | 10 x 100 |
~100 μl | ~100 I.U. | ~90 mm | ~1,75 mm | 10 x 100 |
~110 μl | ~100 I.U. | ~100 mm | ~1,75 mm | 10 x 100 |
~130 μl | ~100 I.U. | ~120 mm | ~1,75 mm | 10 x 100 |
~80 μl | ~100 I.U. | ~54 mm | ~1,90 mm | 10 x 100 |
~115 μl | ~100 I.U. | ~78 mm | ~1,90 mm | 10 x 100 |
~150 μl | ~100 I.U. | ~100 mm | ~1,90 mm | 10 x 100 |
~170 μl | ~100 I.U. | ~100 mm | ~2,00 mm | 10 x 100 |
Analyser Type | Manufacturer | Recommended Blood Gas Capillaries from SC - Sanguis Counting | ||
GEM4000 | IL | 102116 | 102117 | 102118 |
ABL7 | Radiometer | 101122 | 101122 | - |
8 XX | Radiometer | 101122 | 101122 | - |
9x Serie | Radiometer | 101122 | 101122 | - |
8x Serie | Siemens | - | 102120 | - |
12xx Serie | Siemens | - | 102120 | - |
B21 | Roche COBAS | - | 101180 | - |
